Trunk comparison: BMW X2 vs Ford S-MAX
Key Differences
In a direct comparison, several clear differences appear in the trunk and loading geometry: The Ford S-Max offers a longer loading surface when the seats are folded down (+12.6 in / +19%) and also with the first row of seats upright (+7.5 in / +20%).
The trunk opening of the S-Max is significantly higher (+10.6 in / +41%) than that of the BMW X2. The depth from the loading edge to the trunk floor is greater in the BMW X2 (+2.4 in / +200%) and the loading edge above the road is higher (+9.1 in / +40%).
Small width differences favoring the S-Max (narrowest point +1.2 in / +3%; opening width +2.8 in / +7%) are under 10% and less significant.
Implications for Usability
Space for long and bulky items: Due to the longer surface of the S-Max (both with folded seats and with the seat row upright), longer items can be accommodated more easily. The S-Max is thus better suited for furniture parts, skis, or longer luggage.
Height and loading comfort: The significantly higher trunk opening of the S-Max makes it easier to store tall items and insert bulky packages.
The significantly lower loading edge of the S-Max (compared to the X2’s loading edge which is +9.1 in higher) makes lifting heavy items easier and more ergonomic — practical for shopping, strollers, or heavy suitcases.
Internal trunk geometry: The greater distance from the loading edge to the trunk floor in the BMW X2 means more "depth space" below the loading edge; this can help store flat items or luggage deeper and more hidden.
However, combined with the higher loading edge, the effort required to lift items into the vehicle increases.
Width: The differences in internal and opening width are small (<10%) and have little impact on everyday usability; very wide items fit similarly well in both vehicles.
Conclusion: For users who frequently transport long or tall loads or value easy lifting (families, tradespeople, lots of luggage), the Ford S-Max is more practical.
The BMW X2 offers a different geometry with a deeper trunk floor, which can be advantageous for certain packing styles but is less comfortable when handling heavy or tall items due to the higher loading edge.
